22x70mm Brass Heaters
1.8mm Heaters
windows are cut in the middle of the brass to avoid over heating
A variety of brass heaters can be custom-made according to your requirements
Thermocouple is available
1m wire long standard
|
|
19x150mm Brass Heaters
4.2x2.2mm Heaters
The standard thickness of brass wall is 3.5mm
A variety of brass heaters can be custom-made according to your requirements
Thermocouple is inside the 4.2x2.2mm heater
1m wire long standard
|
|
25x240mm Two-part Brass Heaters
The length of the coil heater in the middle is 40mm
The two parts of brass is 140mm and 60mm
The length of both parts can be custom-made according to your requirements
1m long stand wire
|
|
22x250mm Brass Heaters
The standard wall thickness is 3.5mm
The coils at the both ends can be custom-made according to your requirements
1m standard wire
|
|
35x165mm Brass Heaters
The standard wall thickness is 3.5mm
The number of coils at the both ends can be made according to your requirements
The surface is sand-blasted
1m long standard wire
|
|
32x280mm Brass Heaters
The standard wall thickness is 3.5mm
The number of coils at the both ends can be made according to your requirements
The surface is bright metal luster
1m long standard wire
|
|
|
|
|
