32x280mm Brass Heaters
The standard wall thickness is 3.5mm
The number of coils at the both ends can be made according to your requirements
The surface is bright metal luster
1m long standard wire
Technical Specifications
Heater sheath material: 304SS, 316
Max working temperature: 500
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
ID available: 8mm to 90mm
Heater height range: 30mm to 300mm
ID tolerance: +0.03-0.05; -0.00
Power range: 5W to 1500W
Working life: 10,000 hours
Heater cross section optional: 4.2x2.2mm, 3x3mm
Power Density 9w/cm square |
