1m long stand wire
Technical Specifications
Heater sheath material: 304SS, 316L
Max working temperature: 500℃
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
ID available: 15mm to 45mm
铜套高度范围: 30mm至300mm
Heater height range: 30mm to 300mm
ID tolerance: +0.03-0.05; -0.00
Range of working voltage: 12V to 440V
Power range: 5W to 2500W
Working life: 10,000 hours
Heater cross section optional: 4.2x2.2mm, 3x3mm
Power Density：9w/cm²
Power Tolerance：+5% and -10%
TC optional: type J, K, E and T
TC Tolerance: ±5C
Surface treatment: Original metal bright
25x240mm Two-part Brass Heaters
The length of the coil heater in the middle is 40mm
The two parts of brass is 140mm and 60mm
The length of both parts can be custom-made according to your requirements
|
