22x70mm Brass Heaters
1.8mm Heaters
windows are cut in the middle of the brass to avoid over heating
A variety of brass heaters can be custom-made according to your requirements
Thermocouple is available
1m wire long standard
Technical Specifications
Heater sheath material: 304SS, 316L
Max working temperature: 500¡æ
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
ID available: 8mm to 90mm
ÍÌ׸߶ȷ¶Î§: 30mmÖÁ500mm
Heater height range: 30mm to 500mm
ID tolerance: +0.03-0.05; -0.00
Range of working voltage: 12V to 440V
Power range: 5W to 2500W
Working life: 10,000 hours
Heater cross section optional: 4.2x2.2mm, 3x3mm
Power Density£º9w/cm²
Power Tolerance£º+5% and -10%
TC optional: type J, K, E and T
TC Tolerance: ±10¡æ
Surface treatment: Original metal bright |
