35x165mm Brass Heaters
The standard wall thickness is 3.5mm
The number of coils at the both ends can be made according to your requirements
The surface is sand-blasted
1m long standard wire
Technical Specifications
Heater sheath material: 304SS, 316
Max working temperature: 500
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
ID available: 8mm to 90mm
Heater height range: 30mm to 300mm
ID tolerance: +0.03-0.05; -0.00
Power range: 5W to 1500W
Working life: 10,000 hours
Heater cross section optional: 4.2x2.2mm, 3x3mm
Power Density£º9w/cm²
|
