22x250mm Brass Heaters
The standard wall thickness is 3.5mm
The coils at the both ends can be made according to your requirements
1m standard wire
Technical Specifications
Heater sheath material: 304SS, 316
Max working temperature: 500 C
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
ID available: 6mm to 90mm
Heater height range: 30mm to 300mm
ID tolerance: +0.03-0.05; -0.00
Range of working voltage: 12V to 440V
Power range: 5W to 100W
Working life: 10,000 hours
Heater cross section optional: 4.2x2.2mm, 3x3mm
Power Density£º9w/cm² |
