30x40mm Brass Band Heaters
The inside heating elememt is high temperature NiCr wire
The insulation material is high purity MgO powder
1m wire standard
Technical Specifications
Outer tubular material: Brass
Max working temperature: 500¡æ
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
ID available: 30mm to 60mm
Tubular height range: 30mm min.
ID tolerance: +0.03-0.05; -0.00
Range of working voltage: 12V to 440V
Power range: 5W to 800W
Power Tolerance: +5% and -10% |
