ID16x12.7mm Enail Heaters with 1m wire length colorful nylon sleeve
Velcro tape available
XRL 5 pin connector and other connector optional
No connector is the standard
Technical Specifications
Sheath material: 304SS or 316L,10SS
Max working temperature: 700C
High voltage stability test:
Less than 0.5mA leak under 1000V for 30 seconds
Coil OD available: 16mm, 20mm, 25mm,30mm,55mm
ID tolerance: +0.05mm-0.10mm
Range of working voltage: 12V 110V 120V 220V 230V 240V
Power range: 70W 100W 120W 150W
Power Tolerance: +5% and -10%
Working life: 10,000 hours under less than 400Cminus and 2000 hours at 700C
TC optional: type J and K
TC Tolerance: ±10C
Surface treatment: Silver sandblasted
Lead and sleeve: We have a wide variety for your choice
Plugs, Connectors and temperature controller Available: According to requirements |
