Mould Core Thermocouple
The ID of the center hole 4.5mm
The OD of the disk is 14.0mm
1m standard wire of high temperature fiberglass with SS shield
Technical Specifications
TC Type Options: J, K, E
Sheath Material: 304SS or 310SS
Maximal Testing temperature£º400C(1mm) 600C(1.5 and 2mm)
Sensor style options: “Ungrounded” is standard and “Grounded “optional
Accuracy: ±2.5C
High voltage with standing test:
Less than 0.5mA leak under 400V for 30 seconds
Fiberglass with ss shield wire adaptor size 6x30mm
Adaptor can stand the max. temperature: 400C |
