Hot Runner Manifold Thermocouples
The size of the round post is 4.0x11.50mm
The ID of the fore hole is 4.45mm
1m wire standard with high temperature fiberglass insulation and ss shield
Technical Specifications
TC Type Options: J, K, E
Sheath Material: 304SS or 310SS
Maximal Testing temperature£º400C
Sensor style options: “Ungrounded” is standard and “Grounded “optional
Accuracy: +-2.5C
High voltage with standing test:
Less than 0.5mA leak under 400V for 30 seconds
Fiberglass with ss shield wire adaptor size 6x30mm
Adaptor can stand the max. temperature: 400C |
