Technical Details
Outer sheath material: High quality 304SS, 316L
Inside magnesium oxide insulation material: 99.99% high purity magnesium oxide
Heating element: high durance and high temperature NiCr2080 heating elements from Germany
TC material: High quality TC elements to ensure ±5 C tolerance
Max working temperature: 400C
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
OD range: 3mm-32mm
The range of the Total Length: 25mm----2500mm
Maximum power density: 15w/cm²
Unheated zone: 10mm at lead end and about 5mm at bottom
