Technical Specifications
Sheath material: 304SS or 316L
Max working temperature: 700��
High voltage stability test:
Less than 0.5mA leak under 1000V for 30 seconds
ID available: 6m to 40mm
Coil OD available: 20mm to 100mm
ID tolerance: +0.5mm; -0
Range of working voltage: 12V to 440V
Power range: 5W to 1000W
Power Tolerance: +5% and -10%
Working life: 10,000 hours under less than 400�� minus and 2000 hours at 700��
TC optional: type J and K
TC Tolerance: ±10��
Surface treatment: Silver sandblasted or black
Plugs, Connectors and temperature controller Available: According to requirements
