Technical Details
Outer sheath material: High quality 304SS or 316L
Inside magnesium oxide insulation material: 99.99% high purity magnesium
Heating element: high durance and high temperature NiCr2080 heating elements from Germany
Max working temperature: 500��
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
Cross sections optional: 1.8mm, 2.2x1.3mm, 2mm,
The range of the length of heated length: 300mm----1500mm
Max. Power density: 9w/cm²
Length of unheated zone��40mm standard
Dimensions of cold zone adaptor��
3x30mm Double ends small adaptor
8x30mm Single end Standard adaptor
