35x40mm Tubular Heaters
Single outter tubular
The OD can be made after the requirements
1m wire standard
Technical Specifications
Heater sheath material: 304SS or 316L
Outer tubular material: SS304
Max working temperature: 700¡æ
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
ID available: 6mm to 50mm
Tubular height range: 15mm
ID tolerance: +0.05-0.08; -0.00
Range of working voltage: 12V to 440V
Power range: 5W to 2500W
Power Tolerance: +5% and -10%
Working life: 10,000 hours under less than 400¡æ minus and 2000 hours at 700¡æ
TC optional: type J, K, E and T
TC Tolerance: ±10¡æ
Surface treatment: Original metal bright |
