35x200 Coil Heater



ID35x200mm coil heateers 1m standard wire,silicon rubber coated fiberglass sleeve

Wattage and coils can be custom-made

 For other sleeves and special long wire, please contact us

3.5x3.5mm cross section and other sizes optional

The surface is sandblasted,dark green



Technical Specifications

Sheath material: 304SS or 316LS��310SS

Max working temperature: 700��

High voltage stability test:

Less than 0.5mA leak under 1000V for 30 seconds

Coil OD available: 6mm min.

ID Tolerance: ID6mm-10mm +0.00-005mm -0.00mm

              ID11mm-16mm -0.15mm-0.20mm +0.00mm

              ID17mm-22mm -0.20mm-0.25mm +0.00mm

               ID23mm-28mm  -0.25mm-0.30mm +0.00mm

               ID29mm-35mm  -0.30mm-0.35mm +0.00mm

               ID36mm-45mm  -0.35mm-0.40mm +0.00mm

               ID46mm-55mm  -0.40mm-0.45mm +0.00mm

               ID56mm-65mm  -0.45mm-0.50mm +0.00mm

            ID56����  -0.55mm-0.60mm +0.00m

ID Tolerance: ID6mm-10mm +0.00-005mm -0.00mm

                ID11mm-16mm -0.15mm-0.20mm +0.00mm

                ID17mm-22mm -0.20mm-0.25mm +0.00mm

                 ID23mm-28mm  -0.25mm-0.30mm +0.00mm

                 ID29mm-35mm  -0.30mm-0.35mm +0.00mm

                 ID36mm-45mm  -0.35mm-0.40mm +0.00mm

                 ID46mm-55mm  -0.40mm-0.45mm +0.00mm

                 ID56mm-65mm  -0.45mm-0.50mm +0.00mm

               ID56 plus  -0.55mm-0.60mm +0.00mm

           Range of working voltage: 12V 110V 120V 220V 230V 240V

Power range: 50W-1000W

Power Tolerance: +5% and -10%

Working life: 10,000 hours under less than 400�� minus and 2000 hours at 700��

TC optional:  J or K optional

Surface treatment: Silver sandblasted��polished metalic luster

Lead and sleeve: We have a wide variety for your choice

Plugs, Connectors and temperature controller Available: According to requirements
