ID16x50mm coil heateers 1m standard wire,fiberglass sleeve
Wattage and coils can be custom-made
For other sleeves and special long wire, please contact us
4.2x2.2mm cross section and other sizes optional
The surface is sandblasted,dark green
Technical Specifications
Sheath material: 304SS or 316LS��310SS
Max working temperature: 700��
High voltage stability test:
Less than 0.5mA leak under 1000V for 30 seconds
Coil OD available: 6mm min.
ID Tolerance: ID6mm-10mm +0.00-005mm -0.00mm
ID11mm-16mm -0.15mm-0.20mm +0.00mm
ID17mm-22mm -0.20mm-0.25mm +0.00mm
ID23mm-28mm -0.25mm-0.30mm +0.00mm
ID29mm-35mm -0.30mm-0.35mm +0.00mm
ID36mm-45mm -0.35mm-0.40mm +0.00mm
ID46mm-55mm -0.40mm-0.45mm +0.00mm
ID56mm-65mm -0.45mm-0.50mm +0.00mm
ID56���� -0.55mm-0.60mm +0.00m
ID Tolerance: ID6mm-10mm +0.00-005mm -0.00mm
ID11mm-16mm -0.15mm-0.20mm +0.00mm
ID17mm-22mm -0.20mm-0.25mm +0.00mm
ID23mm-28mm -0.25mm-0.30mm +0.00mm
ID29mm-35mm -0.30mm-0.35mm +0.00mm
ID36mm-45mm -0.35mm-0.40mm +0.00mm
ID46mm-55mm -0.40mm-0.45mm +0.00mm
ID56mm-65mm -0.45mm-0.50mm +0.00mm
ID56 plus -0.55mm-0.60mm +0.00mm
Range of working voltage: 12V 110V 120V 220V 230V 240V
Power range: 50W-1000W
Power Tolerance: +5% and -10%
Working life: 10,000 hours under less than 400�� minus and 2000 hours at 700��
TC optional: J or K optional
Surface treatment: Silver sandblasted��polished metalic luster
Lead and sleeve: We have a wide variety for your choice
Plugs, Connectors and temperature controller Available: According to requirements
|
