30x220mm Coil Heaters

ID30x220mm coil heateers 1m standard wire,fiberglass sleeve

Wattage and coils can be custom-made

For other sleeves and special long wire, please contact us

3x3mm cross section and other sizes optional

The surface is sandblasted,dark green

Technical Specifications

Sheath material: 304SS or 316LS，310SS

Max working temperature: 700℃

High voltage stability test:

Less than 0.5mA leak under 1000V for 30 seconds

Coil OD available: 6mm min.

ID Tolerance: ID6mm-10mm +0.00-005mm -0.00mm

ID11mm-16mm -0.15mm-0.20mm +0.00mm

ID17mm-22mm -0.20mm-0.25mm +0.00mm

ID23mm-28mm -0.25mm-0.30mm +0.00mm

ID29mm-35mm -0.30mm-0.35mm +0.00mm

ID36mm-45mm -0.35mm-0.40mm +0.00mm

ID46mm-55mm -0.40mm-0.45mm +0.00mm

ID56mm-65mm -0.45mm-0.50mm +0.00mm

ID56以上 -0.55mm-0.60mm +0.00m

ID Tolerance: ID6mm-10mm +0.00-005mm -0.00mm

ID11mm-16mm -0.15mm-0.20mm +0.00mm

ID17mm-22mm -0.20mm-0.25mm +0.00mm

ID23mm-28mm -0.25mm-0.30mm +0.00mm

ID29mm-35mm -0.30mm-0.35mm +0.00mm

ID36mm-45mm -0.35mm-0.40mm +0.00mm

ID46mm-55mm -0.40mm-0.45mm +0.00mm

ID56mm-65mm -0.45mm-0.50mm +0.00mm

ID56 plus -0.55mm-0.60mm +0.00mm

Range of working voltage: 12V 110V 120V 220V 230V 240V

Power range: 50W-1000W

Power Tolerance: +5% and -10%

Working life: 10,000 hours under less than 400℃ minus and 2000 hours at 700℃

TC optional: J or K optional

Surface treatment: Silver sandblasted，polished metalic luster

Lead and sleeve: We have a wide variety for your choice

Plugs, Connectors and temperature controller Available: According to requirements
