ID20x70mm 热流道加热器，1米长标准线缆，高温玻纤护套，可根据需要定做线缆长度
发热圈的圈数分布根据用户要求定制
可配其他多种材质和颜色的护套，请联系我司索取产品目录本
发热丝线径4.2x2.2mm,可带J,K型热电偶
表面处理为喷砂，抛光或者，墨绿色供选
技术细则
外壳材料：304SS, 316L,高温310SS
Sheath material: 304SS or 316LS，310SS
最高工作温度:
Max working temperature: 700℃
耐压测试标准：1000V高压测试30秒，漏电电流小于0.5mA
High voltage stability test:
Less than 0.5mA leak under 1000V for 30 seconds
外径范围: 大于6mm
Coil OD available: 6mm min.
内径公差范围: ID6mm-10mm +0.00-005mm -0.00mm
ID11mm-16mm -0.15mm-0.20mm +0.00mm
ID17mm-22mm -0.20mm-0.25mm +0.00mm
ID23mm-28mm -0.25mm-0.30mm +0.00mm
ID29mm-35mm -0.30mm-0.35mm +0.00mm
ID36mm-45mm -0.35mm-0.40mm +0.00mm
ID46mm-55mm -0.40mm-0.45mm +0.00mm
ID56mm-65mm -0.45mm-0.50mm +0.00mm
ID56以上 -0.55mm-0.60mm +0.00m
ID Tolerance: ID6mm-10mm +0.00-005mm -0.00mm
ID11mm-16mm -0.15mm-0.20mm +0.00mm
ID17mm-22mm -0.20mm-0.25mm +0.00mm
ID23mm-28mm -0.25mm-0.30mm +0.00mm
ID29mm-35mm -0.30mm-0.35mm +0.00mm
ID36mm-45mm -0.35mm-0.40mm +0.00mm
ID46mm-55mm -0.40mm-0.45mm +0.00mm
ID56mm-65mm -0.45mm-0.50mm +0.00mm
ID56 plus -0.55mm-0.60mm +0.00mm
电压范围: 12V 110V 120V 220V 230V 240V
Range of working voltage: 12V 110V 120V 220V 230V 240V
功率范围：50W-1000W
Power range: 50W-1000W
功率公差: +5% and -10%
Power Tolerance: +5% and -10%
工作寿命: 400℃以下1万小时;700度2千小时
Working life: 10,000 hours under less than 400℃ minus and 2000 hours at 700℃
热电偶: 不可内置热电偶
TC optional: NON
表面处理: 银白色喷砂处理，抛光处理或者墨绿色
Surface treatment: Silver sandblasted，polished metalic luster
引线和护套: 我司提供多种线套供客户选择
Lead and sleeve: We have a wide variety for your choice
插头连接器,温控选择：按客户要求定做
Plugs, Connectors and temperature controller Available: According to requirements |
