ID16x12.7mm 烟具雾化器加热器，1米长线缆，彩色尼龙线套
可配XRL 公插头黑色或者银白色，普通铜插脚，或铜镀金插脚
可配刺扣魔术贴
插头默认接线方式：1，2 电源线 3，4 热电偶正负级，5地线
技术细则
外壳材料：304SS, 316L,高温310SS
Sheath material: 304SS or 316LS，310SS
最高工作温度:
Max working temperature: 700℃
耐压测试标准：1000V高压测试30秒，漏电电流小于0.5mA
High voltage stability test:
Less than 0.5mA leak under 1000V for 30 seconds
外径范围: 16mm, 20mm, 25mm,30mm,55mm
Coil OD available: 16mm, 20mm, 25mm,30mm,55mm
圈内径公差: +0.05mm-0.10mm
ID tolerance: +0.05mm-0.10mm
电压范围: 12V 110V 120V 220V 230V 240V
Range of working voltage: 12V 110V 120V 220V 230V 240V
功率范围：70W 100W 120W 150W
Power range: 70W 100W 120W 150W
功率公差: +5% and -10%
Power Tolerance: +5% and -10%
工作寿命: 400℃以下1万小时;700度2千小时
Working life: 10,000 hours under less than 400℃ minus and 2000 hours at 700℃
热电偶: J型和K型可选
TC optional: type J and K
测温公差: ±10℃
TC Tolerance: ±10℃
表面处理: 银白色喷砂处理或抛光处理
Surface treatment: Silver sandblasted
引线和护套: 我司提供多种线套供客户选择
Lead and sleeve: We have a wide variety for your choice
插头连接器,温控选择：按客户要求定做
Plugs, Connectors and temperature controller Available: According to requirements |
