针式热电偶
直径主要2mm,1.5mm,1mm等
引线为高温玻纤线或者Kapton线
转换接头为不锈钢或者高温塑料
标准引线1米
技术细则
Technical Specifications
热电偶分度号: J, K, E
TC Type Options: J, K, E
直径选择: 1mm, 1.5mm, 2.0mm
Diameter for Options: 1mm, 1.5mm, 2.0mm
外壳材料: 304SS或者310SS
Sheath Material: 304SS or 310SS
最高测试温度：400C(1mm) 600C(1.5 and 2mm)
Maximal Testing temperature：400C(1mm) 600C(1.5 and 2mm)
测温头样式：标准样式（绝缘式）接壳式可选
Sensor style options: “Ungrounded” is standard and “Grounded “optional
测量精度: 正负2.5C
Accuracy: 正负2.5C
耐压测试标准：400V高压测试30秒，漏电电流小于0.5mA
High voltage with standing test:
Less than 0.5mA leak under 400V for 30 seconds
冷端尺寸
Adaptor size
不锈钢屏蔽网玻璃纤维线 冷端尺寸6x30mm
Fiberglass with ss shield wire adaptor size 6x30mm
铁氟龙线或KAPTON线,冷端尺寸 高温塑料头4x20mm
For Teflon and Kapton wire adaptor size 不锈钢头4x30mm
冷端可耐温度：400C
Adaptor can stand the max. temperature: 400C
|
