分流板热电偶
中心圆柱尺寸 4.0x11.50mm
前孔内径 4.45mm
1米标准高温玻纤加不锈钢屏蔽网线
技术细则
Technical Specifications
热电偶分度号: J, K, E
TC Type Options: J, K, E
外壳材料: 304SS或者310SS
Sheath Material: 304SS or 310SS
最高测试温度：400C(1mm) 600C(1.5 and 2mm)
Maximal Testing temperature：400C(1mm) 600℃(1.5 and 2mm)
测温头样式：标准样式（绝缘式）接壳式可选
Sensor style options: “Ungrounded” is standard and “Grounded “optional
测量精度: ±2.5C
Accuracy: ±2.5C
耐压测试标准：400V高压测试30秒，漏电电流小于0.5mA
High voltage with standing test:
Less than 0.5mA leak under 400V for 30 seconds
冷端尺寸Adaptor size
不锈钢屏蔽网玻璃纤维线 冷端尺寸6x30mm
Fiberglass with ss shield wire adaptor size 6x30mm
冷端可耐温度：400C
Adaptor can stand the max. temperature: 400C |
