技术细则 Technical Details
外管材质： 优质304SS或316L
Outer sheath material: High quality 304SS or 316L
内部填充氧化镁粉材料： 美国进口高纯度氧化镁
Inside magnesium oxide insulation material: 99.99% high purity magnesium
发热丝：德国进口高强度，耐高温镍铬2080 电热丝
Heating element: high durance and high temperature NiCr2080 heating elements from Germany
最高工作温度: 500℃
Max working temperature: 500℃
耐压测试标准：1000V高压测试30秒，漏电电流小于0.5mA
High voltage with standing test:
Less than 0.5mA leak under 1000V for 30 seconds
截面尺寸和规格: 1.8mm, 2.2x1.3mm, 2mm, 2.2mm
Cross sections optional: 1.8mm, 2.2x1.3mm, 2mm, 2.2mm
发热条长度范围： 300mm---1500mm
The range of the length of heated length: 300mm----1500mm
最高功率密度: 9w/cm²
Max. Power density: 9w/cm²
不发热区长度: 标准长度40mm
Length of unheated zone：40mm standard
冷区和线转换接头尺寸：
Dimensions of cold zone adaptor：
3x30mm (双端小冷端接头Double ends small adaptor)
8x30mm (单端标准街头Single end Standard adaptor)
